GEEPHON’S SMART BNC-P Series 24/7 DIGITAL SIGNAGE
Delivering the ultimate viewing experience in public spaces with our full metal body design. BNC-P Series’ displays seamlessly integrate into any digital signage environment. With higher brightness, they make a greater impact in transportation hubs, restaurants, command centers, corporate offices, and leisure venues.
Pre-calibrated color temperature
All BNC-P Series displays come with three preset color temperature options—Standard, Cool, and Warm. This ensures consistent optical performance across all screens, regardless of size or production date.
High-End UHD Picture Quality
Experience stunning clarity and vibrant visuals with the entire P Series lineup, supporting native 3840 x 2160 (1920 x 1080 for 32” and 43” series) resolution and HDR compatibility. Elevate your imagery and messaging to new levels of realism and impact!
Robust Daisy Chain Capabilities
BNC-P Series displays support direct daisy chaining of HDMI and LAN inputs, and feature enhanced DisplayPort 1.4 connectivity with HBR3 capabilities. This advanced tech allows a single DisplayPort source to drive up to 4 independent displays, perfect for menu boards and retail applications. Experience the seamless multi-display setups with GEEPHON.
Multi Picture Mode
GEEPHON BNC-P Series displays feature Multi Picture Mode, allowing multiple simultaneous images with individualized color settings. Optimize each section of your display for different content types
effortlessly.
Seamless Wall Mounting
The use of Geephon special mounting brackets kit (optional) allows for seamless installation of equipment and walls. The equipment and walls achieve a fitting effect, and the visual effect is more simple and beautiful.
GComponent Light weight Design
Highly flexible digital screen that can be displayed in either portrait or landscape display orientation.Choose what type of display works best for your business. A comparison between portrait and landscape monitors allow you to identify which digital signage screens work best for your customers and deliver the message that you are trying to convey.
GPlay Convenient U-disk
Automatic content copying, loop playback.
Insert the U disk, automatically copy the contents of the U-disk to the device, and play it automatically. Automatic playback is realized when booted, no additional operation is required.
Fail Over System
The Fail Overrm system can automatically start playing the pictures and videos pre-setting on the device,when the HDMl input fails.
So that the machine can continue to display stably then the Fail Over system will automatically report to the monitoring system, then the team can maintain the device.Make sure our displays are never down.
All-in-One Signage Solution
Gallery
43inch
940.896 x529.254mm
1920 x 1080
16:9
E-LED BLU
700nit
1200:1
25%
16.7M
72%
178°/178°
24/7
8ms
Portrait or Landscape
Android 9.0
ARM Quad Core Cortex-A53 1.5G
Arm Mali-G52 2EE MC1
DDR 2GB
16GB EMMC
Chinese/English
Optional
Optional
Optional / CetusMSC
Yes
Yes
Yes
Yes
USB2.0 x 2 , HDMI IN x 2, Ethernet (RJ45) x 2, RS232 (RJ45) x 1, IR in x 1 , Sensor x 1
HDMI out x 1, Line out x 1
Yes
Optional
Yes
Yes
Yes
IP5X (Front Panel)
N/A
Metal
Black
7.9mm
960.8 x 549.5 x 46.4mm
400 x 400mm
11.2kg
1100 x 690 x 145mm
Indoor
0℃ to +40℃
10% to 80%
-10℃ to +60℃
10% to 80%
100-240V AC，50/60Hz
Built-In Power
<0.5W
80W
Power cord x 1, Remote Control x 1, RS232 Adaptor x 1
