49inch 3000nit High Brightness Open Frame

Features Gallery Specs Download

Enquire to Buy

BOB4923A-AA-30

49inch 3000nit High Brightness Open Frame

Rating

49"55"65"75"86"

Open Frame BOB series

The Open Frame BOB series draws inspiration from the Omni-channel concept, offering clients a customizable design to suit semi-outdoor or full outdoor displays as per their specific requirements. This revolutionary combination of GBright^TM ultra-high brightness, vibrant colors, and GDynamic^TMlocal dimming technology can save up to 45% of energy. Additionally,the GComponent^TM design,known for its space-saving and Eco-friendly features,ensures adaptability across various applications, along with easy installation, cost-effectiveness, andan extended screen lifespan.

GBrightHigh Brightness & Excellent Visibility & Smart Light Sensor

Resolution 2K/4K guarantees true color expression.

You would not “Miss a Thing” with 4500nit highbrightness, which guarantees to deliver excellent picturequality at your shop window,even in direct sunlight.

GBright High Brightness & Excellent Visibility GSunshine^TMTechnology & Smart Light Sensor

Enhanced brightness, color, and color saturation under direct-sunlightto ensure that the picture quality remains great.

SIGNAGE WITH LDM TECHNOLOGY

Energy savings of up to 45% can be achieved at the same brightness.

Contrast ratio up to 450000:1

Compared with traditional digital signageproducts, Geephon ECO DIGITAL SIGNAGEproducts not only have ultra-high displaybrightness, but also ultra-low power

GComponent Lightweight Design

Modularization design of components for easy maintenance, easy fieldremoval and replacement of damaged devices.

Advanced design concept makes the product thinner and lighter. Made of nigh-strengthaluminum alloy material, the product is stronger and greatly reduces weight, easy toinstall and transport.

Gallery

1 / 1

All Spec Print

General

Screen Size
49inch
Screen Active Area
1073.8 x 604mm
Resolution
1920 x 1080
Aspect Ratio
16:9
Type
D-LED BLU
Brightness(nit)
3000nit
Contrast Ratio
1300:1
Dynamic CR
Up to 300000:1
Color Depth
16.7M
Color Gamut
72%
Viewing Angle(H/V)
178°/178°
Operation Hours
24/7
Response Time
8ms
Screen Orientation
Portrait or Landscape

System

OS
N/A
CPU
N/A
GPU
N/A
DDR
N/A
ROM
N/A
Language
Chinese/English

Special

Cloud Advertising Distribution System
N/A
Cloud Splice System
N/A
Smart Monitoring System Cloud
N/A
HDMI Loop
N/A
Ethernet Loop
N/A
Fanless Design
N/A
Dynamic Energy Saving
Yes
HDR
Yes
Local Dimming
Yes
Direct Sunlight Design
Yes
Open API Control Command
N/A
Open RS232 Control Command
Yes
Fail Over Support
N/A

Connectivity

Input
USB2.0 x 1 ,HDMI IN x 1 ,RS232（RJ45） x 1 ,IR in x 1 ,Sensor x 1
Output
Audio out x 1

Network connection

Wifi or LAN
N/A
3G/4G connection
N/A

Speaker

Build in speaker
N/A
Line-out Suppoert
Yes
BT Speaker Support
N/A

Thermal management

Smart Backlight Control
N/A
Smart Temperature Control
N/A
Smart Fans Control
N/A
Overheating protection
N/A

Physical

IP rating
IP5X （Front Panel）
Glass
N/A
Shell
Aluminum
Standard Color
Black
Bezel width(T/L/R/B)
10mm
Dimensions(L/W/D)
1096.18 x 626.4 x 56.85mm
VESA Mount
300 x 250mm
Net Weight
15.1kg
Packing Dimensions(W/H/D)
1224 x 759 x 180mm
20GP container capacity (pcs)
96 PCS
40GP container capacity (pcs)
216 PCS

Operation

Working environment
Indoor window facing
Auto Brightness control
N/A
Operation Temperature (ambient temp.)
0℃ to +40℃ (Direct Sunlight) 0℃ to +50℃ (w/o Direct Sunlight)
Operation Humidity
10% to 80%
Storage Temperature
-10℃ to +60℃
Storage Humidity
10% to 80%

Power

Power Supply
AC 110 /220V,50/60Hz
Power Type
Built-In Power
Standby Power consumption
<0.5W
Max power concumption
250W（Brightness:3000nit）

Accessories

Basic
User manual（Electionic version）

Download

BOB4923A-AA-30_datasheet_Ver1.0

462KB | 20/05/2024
