13inch Equal Bezel Display CTC SERIES

Features Gallery Specs Download

Enquire to Buy

CTC1324A-AA-03

13inch Equal Bezel Display CTC SERIES

Rating

13"15"24"

GEEPHON’S Equal Bezel Display

CTC SERIES

Geephon 13” CTC Series LCD Display. Enhance your visual presentations with precision and elegance, perfectly suited for various exhibition halls, transportation centers, and restaurants.

Physics Tempered Glass, Slim body, Plug & Play Touch Solution

Experience outstanding visual performance with high-definition resolution and remarkable color accuracy. The smooth capacitive touch functionality offers an impeccable interactive experience. Choose Geephon for unmatched display quality.

GPlay Convenient U-disk

Automatic content copying, loop playback.

Insert the U disk, automatically copy the contents of the U-disk to the device, and play it automatically. Automatic playback is realized when booted, no additional operation is required.

All-in-One Signage Solution

Support CMS & MSC
Support SDK/Open API
Support OTA update / upgrade function

Gallery

1 / 1

All Spec Print

General

Screen Size
13inch
Screen Active Area
293.76 x 165.24mm
Touch Technology
10 Point Touch Projected Capacitive
Resolution
1920 x 1080
Brightness(nit)
250nit
Contrast Ratio
1000:1
Viewing Angle(H/V)
178°(H) x 178°(V)(CR≥10)
Operation Hours
24/7

System

CPU
ARM Quad Core Cortex-A53 1.5G
GPU
ARM Mali-G52 2EE MC1
Operating System
Android 9
Memory Storage
DDR 2G EMMC 16GB

Connectivity

Input
Ethernet(RJ45)*1, USB2.0*1, HDMI in*1 DC in*1, type-C*1, Line Out*1

Physical

Glass
Physics Tempered Glass
Standard Color
Black
Dimensions(L/W/D)
332.4 x 206.4 x 55.2mm
Weight (kg)
N.W: 1.8kg G.W:2.2kg
Package(W*H*D)
385 x 280 x 110mm

Operation

Working environment
Indoor
Operation Temperature (ambient temp.)
0°C ~ +40°C
Storage Temperature
-10℃ to +60℃

Power

Power Supply
12V DC

Accessories

Basic
Power Adaptor x 1

Download

CTC1324A-AA-03_datasheet_Ver2.0

660KB | 29/07/2024
